ASME B18.2.2 PDF

Description

ASME B18.2.2 – Nuts for General Applications: Machine Screw Nuts; and Hex, Square, Hex Flange, and Coupling Nuts (Inch Series)

This Standard is intended to cover the complete general and dimensional data for the various types of inch series square and hex nuts, including machine screw nuts and coupling nuts, addressed by this Standard. Also included are appendices covering gaging of slots in slotted nuts, wrench openings for nuts,  formulas on which dimensional data are based, and measurement of bearing surface runout. It should be understood that where questions arise concerning acceptance of product, the dimensions in the tables shall govern over recalculation by formula.

Product Details

Published:

2022

ISBN(s):

9780791875001

ANSI:

ANSI Approved

Number of Pages:

43

File Size:

1 file , 540 KB

Note:

This product is unavailable in Ukraine, Russia, Belarus
