ASME B18.15 – Forged Eyebolts

This Standard is limited to dimensions and capacities for carbon steel and corrosion-resistant stainless steel,forged threaded eyebolts intended primarily for lifting applications. For carbon steel construction, the sizes arelimited to ¼ in. through 2½ in., and for corrosion-resistant stainless steel construction, the sizes are limited to ¼ in. through 1½ in.This Standard covers the following types and styles:

• (a) Type 1, plain pattern (straight shank)

    (1) Style A, long length
    (2) Style B, short length

• (b) Type 2, shoulder pattern

    (1) Style A, long length
    (2) Style B, short length

Nonmandatory Appendices A and B contain descriptive and cautionary information pertinent to forged eyebolts.Nonmandatory Appendix C contains information on the application of eyebolts. Nonmandatory Appendix D provides information on eyebolts with metric threads M6 through M64 and corresponding material and performance information. The inclusion of dimensional data in this Standard is not intended to imply that all products described arestock production items. Consumers should consult with suppliers concerning availability of products.

Product Details

Published:

08/14/2015

ISBN(s):

9780791870198

ANSI:

ANSI Approved

Number of Pages:

22

File Size:

1 file , 770 KB

Redline File Size:

2 files , 4.6 MB

Note:

This product is unavailable in Ukraine, Russia, Belarus
