AS/NZS 1102.104 PDF

Description

AS/NZS 1102.104 – Graphical symbols for electrotechnical documentation, Part 104: Basic passive components

Provides symbols for basic passive components such as resistors, capacitors and inductors, ferrite cores, magnetic storage matrices, piezoelectric crystals, electret and delay lines. Based on but not equivalent to and reproduced from IEC 617-4:1996.

Product Details

Edition:

1st

Published:

12/05/1997

ISBN(s):

073371501

Number of Pages:

20

File Size:

1 file , 120 KB

Product Code(s):

10178517, 10178524, 10178505

Note:

This product is unavailable in Ukraine, Russia, Belarus
